1450nm Raman Amplifier Pump Laser
The 1450 nm band semiconductor laser source output by the single mode fiber adopts high-performance butterfly semiconductor laser, and uses the professionally designed drive circuit and TEC control to ensure the safe and stable operation of the laser. It is suitable to be used as the pump light source of fiber Raman amplifier, and can provide table model or modular packaging.
|
Features: |
Application： |
|
² High output power |
² Fiber laser pumping |
|
² Power and spectral stability |
² Raman amplifier pump |
|
² Module or desktop packaging |
² Nonlinear optical research |
|
Optical index |
unit |
Typical value |
Notes |
|
Operating wavelength |
nm |
1425/1435/1455/1465 |
Optional |
|
Wavelength accuracy |
nm |
±3 |
|
|
output power |
mW |
200/350/500 |
Customizable |
|
Short term stability (15 min) |
dB |
≤ ±0.02 |
|
|
Long term stability (8 hours) |
dB |
≤ ±0.05 |
|
|
Pigtail type |
- |
SMF-28e Single mode |
|
|
Pigtail joint type |
- |
FC/APC |
|
|
Electrical and environmental parameters |
table model |
module |
|
control mode |
Button |
RS232 Serial communication |
|
communication interface |
* Optional |
DB9 Female |
|
Power supply |
100~240V AC, <30W |
5V DC, <15W |
|
Size |
260(W)×280(D)×120(H)mm |
125(W)×150(D)×20(H)mm |
|
Operating temperature range |
-5~+55°C |
|
|
Operating humidity range |
0~70% |
|
|
Order information/Model |
||||
|
FL |
Operating wavelength (nm) |
Output power (mW) |
Output pigtail type |
Package Type |
|
|
1425/1435/1455/1465 |
200/350/500 |
SM=SMF-28e PM=PM1550 |
M=module B=table model |
